Gibson / 1960 JOE WALSH LES PAUL MURPHY AGED / 2013 / Guitar
Joe Walsh 1960 Les Paul Collector's Condition
Gibson Custom lays down the foundation for the Joe Walsh 1960 Les Paul Standard by marrying a solid, lightweight, one-piece, Grade-A mahogany body with a top carved from maple that has been hand selected to match the look of Joe’s original guitar. A thin nitrocellulose “tangerine burst” finish and your choice of hand aging by Tom Murphy or Gibson’s VOS treatment complete the authentic look and feel. A quarter-sawn Grade-A mahogany neck is carved to an accurate 1960 profile that measures 0.800” at the 1st fret and 0.854” at the 12th, and topped with a one-piece, Grade-A rosewood fingerboard with trapezoid inlays made from period-correct cellulose nitrate, and a nylon 6/6 nut at the top end.
To ensure that the Joe Walsh 1960 Les Paul Standard sounds every bit as sublime as it looks, Gibson Custom loads it with a pair of Custom Bucker pickups, made with Alnico III magnets and wound to precisely match the specs of Joe’s original PAF humbuckers. The traditional four-knob Les Paul control complement includes “bumble bee” tone capacitors on the tone potentiometers, and a three-way pickup selector.
The accurate ABR-1 Tune-o-matic bridge is set up with its saddles slanted precisely as found on Joe’s original guitar, and partners with a lightweight aluminum stopbar tailpiece. A set of Grover™ kidney-button tuners, a common upgrade on guitars of the era, offer smooth and precise tuning. The body and fingerboard binding, pickguard, truss-rod cover, switch ring, and control cavity covers are all period-correct for shape and color, and the guitar’s controls carries four gold Top Hat knobs with silver Vol/Tone inserts.
All guitars include a Gibson Custom hardshell case. Fifty guitars will be hand-aged by Tom Murphy and signed by the artist and come complete with a leather-bound Certificate of Authenticity. All guitars include Certificate of Authenticity, owner’s manual and adjustment literature, and are covered by Gibson Custom’s Limited Lifetime Warranty and 24/7/365 Customer Service.
| Top | Figured Maple |
| Back | Mahogany |
| Binding | .90 Cream |
| Adhesive | Franklin Titebond |

| Species | Genuine Mahogany Neck with a Maple Spline |
| Profile | 1960 Profile |
| Truss Rod | Historic Truss Rod Assembly (No Tubing) |
| Joint Angle | 4° (+/- 15 seconds) |

| Joint | Mortise & Tenon |
| Adhesive | Hot Hide Glue |
| Joint Angle Tolerance | +/- .005″ |

| Species | Rosewood |
| Radius | 12″ |
| Scale Length | 24.75″ |
| Binding | .04 Cream Reissue |
| Inlays | Nitrocellulose Trapezoid Inlays |
| Nut/E.O.B | 1.687/2.062 |

| Material | Nylon |
| Width | 1.687 |
| Slots | Gibson PLEK System |

| Inlay | Gibson Pearl |
| Truss Rod Cover | Vintage |
| Angle | 17 Degrees |

| Model | Grover™ Kidney |
| Tuning Ratio | 12:01 |
| Plating | Nickel |

| Type | ABR-1 |
| Plating | Nickel |

| Type | Lightweight Aluminum Stop Bar |
| Plating | Nickel |

| Knobs | Gold Top Hats with Silver Inserts and Dial Pointers |
| Toggle Switch Washer | Cream with Gold Silkscreen |
| Pickguard | Reissue Cream |
| Pickup Mounting Rings | Cream |
| Control Plate Cover | Black |
| Strings | .010 – .046 |
| Strap Buttons | Aluminum Gibson End Pins |

| Neck Position | Custom Bucker (Alnico III) |
| Bridge Position | Custom Bucker (Alnico III) |

| Potentiometers | 2 Volume Controls, 2 Tone Controls |
| Capacitors | Bumblebee |
| Toggle Switch | Three-Way with Cream Toggle Cap |
| Output Jack | Traditional ¼” |

| Type | Custom Shop Hardshell |

| Certificate of Authenticity | Aged and Signed models as well as the Aged models are presented in a leather bound folder while the VOS are presented in a standard Custom Shop folder |
| Additional Materials | Each Joe Walsh 1960 Les Paul comes with extra switch plate, adjustment literature, and documentation for the guitar’s limited lifetime warranty. |
